RCBO DGB1NLE-63HS

DGB1NLE-63HS

DGB1NLE-63HS series residual current circuit breaker with overcurrent protection is mainly used in AC 50Hz with rated working voltage 230V and with rated current up to 63A. In case of personal electric shock or when the grid leakage current exceeds the specified value, the residual current action circuit breaker can work to quickly cut off the power supply within the very short time for protection of the safety of personnel and electrical equipment as infrequent conversion of the line under the overload, short-circuit, overvoltage and normal situations, especially suitable for industrial and business lighting power distribution system.

Quantity:

Contact Now

add to cart

Product name	DGB1NLE-63HS (Electronic)	DGB1NL-63HS (ELectromagnetic)
Standards	IEC61009-1	IEC61008-1
Certificate	CE, CB	CE,CCC,CB
Electrical characteristics
Number of poles	1P+N	1P+N
Rated frequency (Hz)	50/60	50/60
Frame current (A)Inm	63	63
Rated current (A)In	6,10,16,20,25,32,40,50,63	6,10,16,20,25,32,40,50,63
Rated voltage (V)	AC230	AC230
Rated insulation voltage (V)Ui	500	500
Rated impulse withstand voltage (kV)Uimp	4	4
Rated short-circuit breaking capacity (kA)Ics	6	6
Rated short-circuit breaking capacity (kA)Icn	6	6
Instantaneous trip characteristics	B,C,D	B,C,D
Trip form	Thermal, magnetic and Lekage trip	Thermal, magnetic and Lekage trip
Pollution level	2	2
Rated residual action current (mA)	30/50/100/300	30/50/100/300
Max. breaking time at the rated residual current	0.1s	0.1s
Wave form of earth leakage sensed	AC / A	AC / A
Overvoltage protection: Uvo=280V±5%	optional	/
Electrical and mechanical accessories	MX: Shunt release, OF: Auxiliary contact, SD: Alarm contact,MX+OF: Shunt release + auxiliary contactMV: Overvoltage release MN: Undervoltage release MV+MN: Overvoltage and undervoltage release	MX: Shunt release, OF: Auxiliary contact, SD: Alarm contact,MX+OF: Shunt release + auxiliary contactMV: Overvoltage release MN: Undervoltage release MV+MN: Overvoltage and undervoltage release
