RCBO Lamp Light

RCBO DBL1-40LED lamp light

DBL1-40LED
DBL1-40LED Residual current circuit breaker with integral overcurrent protection with LED status signalisation series breake with overcurrent protection is mainly used in AC 50Hz with rated working voltage 230V and with rated current up to 40A. Compact electromagnetic rcbo, 2 poles with protection, 6KA up to 40A, Hot sale in Europ market
Quantity:
Contact Now
add to cart


Product name

DBL1-40LED

Standards

IEC61009-1

Certificate

Kema CE, CB

Electrical characteristics

Number of poles

2P

Rated frequency (Hz)

50/60

Frame current (A)Inm

63

Rated current (A)In

6,10,16,20,25,32,40

Rated voltage (V)

AC230

Rated insulation voltage (V)Ui

500

Rated impulse withstand voltage (kV)Uimp

4

Rated short-circuit breaking capacity (kA)Ics

6

Rated short-circuit breaking capacity (kA)Icn

6

Instantaneous trip characteristics

B,C,D, CK,K

Trip form

Thermal, magnetic and Leakage trip

Pollution level

2

Rated residual action current (mA)

30/50/100/300

Max. breaking time at the rated residual current

0.1s

wave form of earth leakage sensed

AC / A

LED signalisation

Red/Yellow/Green; Permanent light green: Normal operation; Permanent light yellow: The currently measured residual current is higher than 30% I∆n. The system is cur- rently drawing a fault current, and actions should be taken accordingly; Permanent light red: The currently measured residual current is higher than 50% I∆n. The system is currently drawing a critical amount of fault current, and actions should be taken immediately; Flashing yellow/red: Please press the test button (T). If the LEDs are still present, please refer to the inst- ruction leaflet.
