RCBO Modular

RCBO DGB1LE-63HS modular

DGB1LE-63HS
DGB1LE-63HS series Residual current circuit breaker with overload protection is mainly used in AC 50Hz with rated working voltage 230V and with rated current up to 63A. In case of personal electric shock or when the grid leakage current exceeds the specified value, the residual current action circuit breaker can work to quickly cut off the power supply within the very short time for protection of the safety of personnel and electrical equipment as infrequent conversion of the line under the overload, short-circuit, overvoltage and normal situations, especially suitable for industrial and business lighting power distribution system.
Quantity:
Contact Now
add to cart


Product name

DGB1LE-63HS (Electronic)

DGB1L-63HS (Eletromagnetic)

Standards

IEC61009-1

IEC61008-1

Certificate

CE, CB

CE, CCC, CB

Electrical characteristics

Number of poles

1P+N,2P,3P,3P+N,4P

1P+N,2P,3P,3P+N,4P

Rated frequency (Hz)

50/60

50/60

Frame current (A)Inm

63

63

Rated current (A)In

6,10,16,20,25,32,40,50,63

6,10,16,20,25,32,40,50,63

Rated voltage (V)

AC240V/415V (230V/400V)

AC240V/415V (230V/400V)

Rated insulation voltage (V)Ui

500

500

Rated impulse withstand voltage (kV)Uimp

4

4

Rated short-circuit breaking capacity (kA)Ics

6

6

Rated short-circuit breaking capacity (kA)Icn

6

6

Instantaneous trip characteristics

B,C,D, CK,K

B,C,D, CK,K

Trip form

Thermal, magnetic and Lekage trip

Thermal, magnetic and Lekage trip

Pollution level

2

2

Rated residual action current (mA)

30/50/100/300

30/50/100/300

Max. breaking time at the rated residual current

0.1s

0.1s

Wave form of earth leakage sensed

AC / A

AC / A

Overvoltage protection: Uvo=280V±5%

optional

/

Electrical and mechanical accessories

MX: Shunt release, OF: Auxiliary contact, SD: Alarm contact,MX+OF: Shunt release + auxiliary contactMV: Overvoltage release

MN: Undervoltage release MV+MN: Overvoltage and undervoltage release

MX: Shunt release, OF: Auxiliary contact, SD: Alarm contact,MX+OF: Shunt release + auxiliary contactMV: Overvoltage release

MN: Undervoltage release MV+MN: Overvoltage and undervoltage release
