MCB DGB8-63 4.5kA
DGB8-63
DGB8-63 Miniature Circuit Breakers with 4.5KA/6kA breaking capacity was designed to provide protection against short circuit and overload for domestic,commercial and industrial electrical installations.
Quantity:
Product name | DGB8-63 |
Standards | IEC60898- 1 |
Certificate | CE, CB |
Electrical characteristics | |
Number of poles | 1P,2P,3P,4P |
Rated frequency (Hz) | 50/60 |
Frame current (A) Inm | 63 |
Rated current (A) In | 1,2,3,4,5,6,10,16,20,25,32,40,50,63 |
Rated voltage (V) | AC230/400(1P) AC400(2P,3P,4P) |
Rated insulation voltage (V) Ui | 690 |
Rated impulse withstand voltage (kV)Uimp | 4 |
Rated short-circuit breaking capacity (kA)Ics | 4.5 / 6 |
Rated short-circuit breaking capacity (kA)Icn | 4.5 / 6 |
Instantaneous trip characteristics | B,C,D |
Trip form | Thermal magnetic trip |
Pollution level | 2 |
Electrical and mechanical accessories | MV+MN2 (overvoltage and undervoltage), OF2 (auxiliary), SD2 (alarm), MX2 (shunt) |
