MCB DGB3-63E

DGB3-63E

DGB3-63/DGB3-63E Miniature Circuit Breakers with 4.5KA/6kA breaking capacity was designed to provide protection against short circuit and overload for domestic,commercial and industrial electrical installations.
Economic type, 4.5KA and 6KA brekaing capacity for option

Quantity:

Contact Now

add to cart

Product name	DGB3-63	DGB3-63E
Standards	IEC60898-1	IEC60898-1
Certificate	CE, CB	CE, CB
Electrical characteristics
Number of poles	1P,2P,3P,4P	1P,2P,3P,4P
Rated frequency (Hz)	50/60	50/60
Frame current (A) Inm	63	63
Rated current (A) In	1,2,4,5,6,10,16,20,25,32,40,50,63	1,2,4,5,6,10,16,20,25,32,40,50,63
Rated voltage (V)	AC240V/415V (230V/400V)	AC240V/415V (230V/400V)
Rated insulation voltage (V) Ui	690	690
Rated impulse withstand voltage (kV)Uimp	4	4
Rated short-circuit breaking capacity (kA)Ics	6	4.5
Rated short-circuit breaking capacity (kA)Icn	6	4.5
Instantaneous trip characteristics	B,C,D	B,C,D
Trip form	Thermal magnetic trip	Thermal magnetic trip
Pollution level	2	2
Electrical and mechanical accessories	MV+MN2 (overvoltage and undervoltage), OF2 (auxiliary), SD2 (alarm), MX2 (shunt)	MV+MN2 (overvoltage and undervoltage), OF2 (auxiliary), SD2 (alarm), MX2 (shunt)
