DPNL RCBO DGB1LE-40H A type SAA
DGB1LE-40H
DGB1LE-40H series Residual current circuit breaker with overload protection is mainly used in AC 50Hz with rated working voltage 230V and with rated current up to 40A. In case of personal electric shock or when the grid leakage current exceeds the specified value, the residual current action circuit breaker can work to quickly cut off the power supply within the very short time for protection of the safety of personnel and electrical equipment as infrequent conversion of the line under the overload, short-circuit, overvoltage and normal situations, especially suitable for industrial and business lighting power distribution system.
Quantity:
Product name | DGB1LE-40H |
Standards | IEC61009-1 |
Certificate | SAA,CE, CCC, CB,TUV |
Electrical characteristics | |
Number of poles | 1P+N |
Rated frequency (Hz) | 50/60 |
Frame current (A)Inm | 40 |
Rated current (A)In | 6,10,16,20,25,32,40 |
Rated voltage (V) | AC230 |
Rated insulation voltage (V)Ui | 500 |
Rated impulse withstand voltage (kV)Uimp | 4 |
Rated short-circuit breaking capacity (kA)Ics | 6 |
Rated short-circuit breaking capacity (kA)Icn | 6 |
Instantaneous trip characteristics | B,C,D |
Trip form | Thermal, magnetic and Lekage trip |
Pollution level | 2 |
Rated residual action current (mA) | 30/50/100/300 |
Max. breaking time at the rated residual current | 0.1s |
Wave form of earth leakage sensed | AC / A |
Overvoltage protection: Uvo=280V±5% | optional |
