RCCB DGL2-63EV DC6mA charge protect
DGL2-63EV
These RCCBs are designed for use in charging stations for electric vehicles, Not permitted for protecting systems in which electronic
equipment may cause residual currents with frequencies not equal to 50 Hz. AC/DC sensitive residual current circuit-breakers of type B or B+ must be used in this case, DC6mA.
equipment may cause residual currents with frequencies not equal to 50 Hz. AC/DC sensitive residual current circuit-breakers of type B or B+ must be used in this case, DC6mA.
Quantity:
Product name | DGL2-63 EV |
Standards | IEC61008-1/IEC62955:2018 |
Certificate | CE, CB |
Electrical characteristics | |
Number of poles | 2P/4P |
Rated frequency (Hz) | 50/60 |
Frame current (A)Inm | 63 |
Rated current (A)In | 16,20,25,32,40,50,63 |
Rated voltage (V) | AC240V/415V (230V/400V) |
Rated insulation voltage (V)Ui | 500 |
Rated impulse withstand voltage (kV)Uimp | 4 |
Rated short-circuit breaking capacity (kA)Ics | 7.5 |
Rated short-circuit breaking capacity (kA)Icn | 10 |
Trip form | A type functionality : voltage independent DC functionality: voltage dependent |
Pollution level | 2 |
Rated residual action current (mA) | 30100/300 |
Max. breaking time at the rated residual current | 0.1s |
wave form of earth leakage sensed | B |
DC tripping threshold | 6 mA |
Sensitivity | Alternating, pulsed and smooth direct currents |
