RCCB DGL2-63 125 A type
DGL2-125
DGL2-125 series residual current circuit breaker (hereinafter referred to as the circuit breaker) is mainly used in AC 50Hz circuit with rated voltage 400V and rated current up to 125A. In case of personal electric shock or when the grid leakage exceeds the specified value, the residual current circuit breaker can quickly cut off the power supply in a very short time for protection of the safety of people and electrical equipment and also for infrequent changeover of line and infrequent start of motor. This product is suitable for various places such as industry, business, and high-rise residential buildings
Electromagnetic type, Max current up to 125A,
Electromagnetic type, Max current up to 125A,
Quantity:
Product name | DGL2-63 | DGL2-125 |
Standards | IEC61008-1 | IEC61008-1 |
Certificate | Kema CE, CB | Kema CE, CB |
Electrical characteristics | ||
Number of poles | 2P/4P | 2P/4P |
Rated frequency (Hz) | 50/60 | 50/60 |
Frame current (A)Inm | 63 | 125 |
Rated current (A)In | 16,20,25,32,40,50,63 | 80,100,125 |
Rated voltage (V) | AC240V/415V (230V/400V) | AC240V/415V (230V/400V) |
Rated insulation voltage (V)Ui | 500 | 500 |
Rated impulse withstand voltage (kV)Uimp | 4 | 4 |
Rated short-circuit breaking capacity (kA)Ics | 7.5 | 7.5 |
Rated short-circuit breaking capacity (kA)Icn | 10 | 10 |
Trip form | Leakage trip | Leakage trip |
Pollution level | 2 | 2 |
Rated residual action current (mA) | 30100/300 | 30100/300 |
Max. breaking time at the rated residual current | 0.1s | 0.1s |
wave form of earth leakage sensed | AC / A / G / S / F | AC / A / G / S / F |
