OUPA self-recovery control DGGQ2-63

DGGQ2-63 self-recovery over-voltage andunder-voltage protector(hereinafter referred to as the protector) is suitable for load line with ACvoltage single-phase 230V/three-phase 400V,frequency 50/60 Hz, rated operating current 63A and below.

When the circuit  voltage is abnormal due to single-phase (three-phase) over-voltage caused by the neutral ine fault in the circuit, serious unbalanced three-phase load, too large line resistance, phase loss or high-order harmonics, the protector can automatically disconnect the load-side power supply, thereby preventing damage to the electrical equipment and realizing theprotectionoftheelectrical equipment.

Also,theprotector can automatically detect the line voltage, and can automatically close when the line has a normal voltage, thereby restoring the power supply to the electrical equipment. The product shall be used in series with a circuit breaker, mainly used in the incoming branch box or other power distribution lines to be protected in the civil and commercial buildings.

Electromagnetic compatibility (EMC)
Electrostatic discharge	8kV (air discharge) / 6kV (contact discharge)
Radio frequency radiation	3V/m 80MHz ～ 1000MHz
Transient shock	4kV 2.5kHz
Surge	±4kV
Radio frequency conducted interference	3V 0.15 ～ 80MHz
Voltage sags and interruptions	Class 2
