Disconnector switch DGG1-125
DGG1-125
DGG1-125 Switch Disconnectors are designed to isolate the main circuit. They can match DGB1 series MCBs and RCBOs for consumer unit installations for residential, commercial and industrial buildings and premises.
Quantity:
Product name | DGG1-125 |
Standards | IEC60947- 3 |
Certificate | KEMA, CE, SEMKO, CB |
Electrical characteristics | |
Number of poles | 1P,2P,3P,4P |
Rated frequency (Hz) | 50/60 |
Frame current (A) Inm | 125 |
Rated current (A) In | 32, 40, 50, 63, 80, 100, 125 |
Rated voltage (V) Ue | AC230/400(1P,2P) AC400(3P,4P) |
Rated insulation voltage (V) Ui | 690 |
Rated impulse withstand voltage (kV) Uimp | 4 |
Rated short-time withstand current (kA) Icw | 12 Ie / 1s |
Rated short-circuit making capacity (kA) Icm | 20 Ie / 0.1s |
Rated making and breaking capacity (kA) Icm | 3 Ie |
Pollution class | III |
