Bell transformer BT16
BT16
Applicable to the circuit with rated voltage 230V~ and rated frequency 50/60Hz, used to power electric bell of extra-low voltage.
●Safe electrical separation between primary and secondary circuit
●Provides extra low voltage up to 24V
●Low temperature rising
●High output accuracy
●Extra overload capacity up to 25% within 24 hours
●Safe electrical separation between primary and secondary circuit
●Provides extra low voltage up to 24V
●Low temperature rising
●High output accuracy
●Extra overload capacity up to 25% within 24 hours
Quantity:
Approvals | CE |
Rated input voltage | 230V AC |
Rated output voltage | BT16: 8, 12, 24V |
BT8: 4, 6, 8, 12, 16, 24V | |
Rated frequency | 50/60Hz |
Rated power output | 8VA |
Consumption | 1.15W |
Service period | Continuous operating |
Pollution class | 2 |
Connection terminals | Pillar terminal with clamp |
Connection capacity | Rigid conductor 10mm2 |
Installation | On symmetrical DIN rail 35mm |
Panel mounting |
